I had the opportunity to use the LS55 fluorescence spectrometer from Perkin Elmer. We use categories like tags.I am working at the Department of Biophysics, Panjab University, Chandigarh, India as a Senior Research Fellow.

Dimensions (W×D×H): approximately, 2.5' X 2' X 8"Īdd any other categories that may be relevant to your page.

A single position water thermostattable holder for 10mm cuvettes.

using the Raman band of water with excitation at 350 nm.

Computer selectable cut-off (high pass) at 290, 350, 390, 430, and 515nm.

Spectral bandpass:2.5-20.0nm, selected in 0.1nm increments.

Range: 200nm-650nm with standard photomultiplier with zero order selectable 200-900m with optional R928 photomultiplier.

Spectral bandpass: 2.5-15.0nm, selected in 0.1nm increments.

Range: 200-800nm with zero order selectable.

Reference detector: Photodiode, max operation ~900nm.

Red-sensitive R928 photomultiplier (optional), max operation ~900nm.

Gated photomultiplier with modified S5 response, max operation ~650nm.

Source: Xenon discharge lamp, equivalent to 20kW for 8μs duration.

Spectral bandwidth: 1nm (190 to 1100nm).

The other High voltage label is located inside the instrument on top of the monochromator cover.

The caution label is coupled with a high voltage label.

At the front left of the instrument, by the hand screw that fixes the top cover, the caution label warns that removing the cover can expose hazardous voltages.

Near the mains inlet fuse, the caution label warns users that the operator replaceable fuse is a CSA approved fuse, not an IEC fuse.

In the sample area, the caution label warns users of the potential for eye damage caused by staring into the beam in the sample compartment.

#PERKIN ELMER WINLAB MANUAL#

There are three Caution labels on the instrument, indicating that the user's manual needs to be consulted.

The event marker button on the front plate accessory can be used for identification of times when reagents are added to the cuvette.Using the Read application, the intensity, polarization, or anisotropy data can be collected simultaneously with the temperature and saved as a spreadsheet.After the sensor is calibrated using the FL WinLab LS55 Status application, the application will automatically record the temperature at the start of data collection in the result dataset header.The temperature sensor located in the block of the cellholder will report the temperature of the sample.The stirrer status can be set to low, high, or off by clicking the accessory icon.It holds 12.5mm square (10 mm pathlength) cuvettes and can be thermostatted using circulated water.This cell holder requires no alignment or set up.The door to sample compartment should be closed before samples are run.Samples can be placed into the sample compartment.After instruments calibrated and self checked, proceed to toolbar to select methods.

#PERKIN ELMER WINLAB WINDOWS#

When Windows has completely loaded, start the FL WinLab software.The instrument should be completely switched on before switching on the computer.It takes about 1 minutes to initialize.When the switch is turned on, the neon lamp on the front lower left-hand side of the instrument is lit.There is a on/off switch located on the left-hand side of the instrument's panel.contact with questions or to schedule access via email.access to the laboratory is restricted see Dr.Wavelength kinetics (both single and multiple wavelengths).Flat samples, like TLC plates and electrophoresis gels, can be analyzed using the plate reader accessory.Fluorescence, phosphorescence and bio- and chemi-luminescence.The polarizer is controlled by the software. The automated polarizer has two filter wheels that have both a horizontal and vertical polarizing element. Included with the LS55 Perkin Elmer Fluorescence Spectrometer, 230V is a single-cell sample holder that can hold up to a 1cm pathlength cell and has the option of stirring. The instrument also has the ability to prescan the sample to determine the excitation peak and maximum emission. The excitation and emission monochromators can be used independently or simultaneously.

#PERKIN ELMER WINLAB SOFTWARE#

The FL WinLab™ software has different modes operation like Scan, TimeDrive, and Ratio Data Collection, increasing the versatility of the instrument. The LS55 Perkin Elmer Fluorescence Spectrometer, 230V uses a pusled Xenon source to measure fluorescence, phosphorescence, chemi- and bio- luminescence. This is a 0.1nm resolution, compact spectrophotometer that uses the windows-compatible FL WinLab™ software that can measure fluorescence, phosphorescence and bio- and chemi-luminescence using a pulsed Xenon lamp source.Perkin Elmer LS 55 Fluorescence Spectrometer.
